Troubleshooting the Smallstep Agent

This guide helps you diagnose and resolve common issues with the Smallstep Agent. The agent includes built-in diagnostic tools to help identify problems quickly.

Before troubleshooting, ensure your system meets the requirements:

• Review System Requirements
• Check Runtime Requirements
• Verify Connectivity Requirements

The Smallstep Agent includes a doctor command that performs automated health checks and provides diagnostic information. This is the recommended first step when troubleshooting issues.

On macOS:

step-agent-plugin doctor

On Windows:

& 'C:\Program Files\Smallstep\SmallstepApp\smallstep-agent.exe' doctor

On Linux:

sudo step-agent-plugin doctor

The doctor command runs a series of checks and displays results in a table format:

+------------------------------------------+--------+-------------+
| Check                                    | Status | Description |
+------------------------------------------+--------+-------------+
| Check runtime requirements               | PASS   |             |
| Ping the agent                           | PASS   |             |
| Check attestation CA connectivity        | PASS   |             |
| Check API gateway connectivity           | PASS   |             |
| Check mission control connectivity       | PASS   |             |
| Bootstrap certificate authorities        | PASS   |             |
| Verify issued certificates               | PASS   |             |
| Sign with endpoint keys                  | PASS   |             |
| Enumerate PKCS#11 objects                | PASS   |             |
+------------------------------------------+--------+-------------+

Each check validates a specific aspect of the agent's functionality. A PASS status means the check succeeded, while FAIL indicates a problem that needs attention.

What it checks: Verifies that your system has the necessary components for the agent to function:

• TPM 2.0 availability - Ensures the Trusted Platform Module is accessible and can create/delete keys
• systemd (Linux only) - Confirms systemd is running for managing network connections

Common failure reasons:

• No TPM 2.0 module present or enabled in BIOS/UEFI
• TPM is locked or inaccessible
• User lacks permissions to access the TPM (Linux)
• systemd is not the init system (Linux)

Troubleshooting steps:

1. Verify TPM 2.0 is enabled in your system BIOS/UEFI settings
2. On Linux, check TPM permissions: ls -l /dev/tpm*
3. On Linux, ensure the user has read/write access to /dev/tpmrm0
4. On Windows, verify TPM is enabled: Run tpm.msc or check Device Manager
5. On Linux, confirm systemd is running: ps -p 1 -o comm=

What it checks: Verifies the agent background service is running and responding to IPC requests.

Common failure reasons:

• Agent service is not running
• Agent service crashed or failed to start
• IPC socket is inaccessible

Troubleshooting steps:

1. Check if the agent service is running:
   • macOS: Look for Smallstep in Activity Monitor
   • Windows: Check Task Manager for the Smallstep Agent process
   • Linux: Run sudo systemctl status step-agent
2. Restart the agent service:
   • macOS/Windows: Restart from the desktop app or System Settings
   • Linux: Run sudo systemctl restart step-agent
3. Check agent logs for error messages:
   • Linux: Run sudo journalctl -u step-agent -n 50

What it checks: Tests network connectivity to att.smallstep.com (TPM Attestation CA).

Common failure reasons:

• Firewall blocking outbound HTTPS connections
• Proxy configuration required but not set
• Network connectivity issues
• DNS resolution failure

Troubleshooting steps:

1. Test connectivity manually: curl -v https://att.smallstep.com
2. Check firewall rules allow HTTPS to att.smallstep.com
3. If behind a proxy, ensure proxy settings are configured
4. Verify DNS resolution: nslookup att.smallstep.com

What it checks: Tests network connectivity to gateway.smallstep.com (Smallstep API).

Common failure reasons:

• Same as attestation CA connectivity issues

Troubleshooting steps:

1. Test connectivity manually: curl -v https://gateway.smallstep.com
2. Check firewall rules allow HTTPS to gateway.smallstep.com
3. Review network and proxy configuration

What it checks: Tests gRPC connectivity to control.infra.smallstep.com:443 (Agent API).

Common failure reasons:

• Firewall blocking port 443 for gRPC traffic
• Deep packet inspection interfering with gRPC
• Proxy not configured for gRPC

Troubleshooting steps:

1. Test connectivity manually: curl -v https://control.infra.smallstep.com
2. Check firewall rules allow HTTPS/gRPC to control.infra.smallstep.com
3. Some corporate firewalls may block gRPC - work with your network team

What it checks: Verifies the agent can retrieve and validate CA root certificates from your Smallstep team's CA.

Common failure reasons:

• Connectivity issues to <your-team>.ca.smallstep.com
• Invalid or expired CA fingerprint in configuration
• Agent not properly registered with your team

Troubleshooting steps:

1. Verify connectivity to your CA: curl -v https://<your-team>.ca.smallstep.com
2. Check the agent configuration file for correct team name and fingerprint:
   • macOS/Windows: Configuration in app settings
   • Linux: Check /etc/step-agent/agent.yaml
3. Ensure the device is approved in your Smallstep console

What it checks: Validates that all endpoint certificates are currently valid (not expired or not yet valid).

Common failure reasons:

• Certificates expired due to agent being offline
• System clock is incorrect
• Certificate renewal failed

Troubleshooting steps:

1. Verify system clock is accurate: date
2. If clock was wrong, correct it and restart the agent
3. Check when certificates will expire (look in agent logs or desktop app)
4. Run doctor with --renew flag to force certificate renewal (see below)

What it checks: Tests that the agent can perform cryptographic signing operations with endpoint keys stored in the TPM/Secure Enclave.

Common failure reasons:

• TPM/Secure Enclave access issues
• Keys were deleted or corrupted
• Permission issues accessing keys

Troubleshooting steps:

1. Verify TPM/Secure Enclave is accessible (see runtime requirements above)
2. Check agent logs for key access errors
3. If keys are corrupted, the agent may need to re-register

What it checks: (Linux/macOS only) Verifies that certificates and keys are accessible via the PKCS#11 interface.

Common failure reasons:

• PKCS#11 server not running
• P11_KIT_SERVER_ADDRESS environment variable not set correctly
• p11-kit not installed or configured

Troubleshooting steps:

1. Verify the PKCS#11 socket exists:

   ls -l $XDG_RUNTIME_DIR/step-agent/step-agent-pkcs11.sock


2. Check the environment variable:

   echo $P11_KIT_SERVER_ADDRESS


3. Test PKCS#11 manually:

   pkcs11-tool --module /usr/lib/x86_64-linux-gnu/pkcs11/p11-kit-client.so --list-slots


4. See PKCS#11 Support for configuration details

To test certificate renewal as part of the doctor checks, use the --renew flag:

step-agent-plugin doctor --renew

This will attempt to renew all endpoint certificates and report any failures. This is useful when:

• Certificates are close to expiration
• Testing the renewal workflow
• Recovering from a certificate expiration issue

For scripting or integration with monitoring tools, use the --json flag:

step-agent-plugin doctor --json

This outputs check results in JSON format:

{
	"authorities": {
		"Description": "",
		"State": "PASS"
	},
	"certificates": {
		"Description": "",
		"State": "PASS"
	},
	"network-attestation": {
		"Description": "",
		"State": "PASS"
	},
	"network-control": {
		"Description": "",
		"State": "PASS"
	},
	"network-gateway": {
		"Description": "",
		"State": "PASS"
	},
	"ping": {
		"Description": "",
		"State": "PASS"
	},
	"preflight": {
		"Description": "",
		"State": "PASS"
	},
	"sign": {
		"Description": "",
		"State": "PASS"
	}
}

Symptoms:

• Agent service fails to start
• Desktop app shows "Agent not running"
• Doctor ping check fails

Solutions:

1. Check system requirements are met
2. Run step-agent-plugin doctor to identify specific issues
3. Check agent logs for startup errors
4. Restart the system if the TPM is in an inconsistent state
5. On Linux, check for conflicting services using the same ports

Symptoms:

• All network checks fail in doctor output
• Agent shows "offline" status
• Certificate renewal fails

Solutions:

1. Verify internet connectivity: ping 8.8.8.8
2. Test DNS resolution: nslookup gateway.smallstep.com
3. Review Connectivity Requirements
4. Check corporate firewall and proxy settings
5. Ensure all required Smallstep hosts are allowlisted

Symptoms:

• "Verify issued certificates" check fails
• Applications can't authenticate
• Certificate errors in browser or VPN

Solutions:

1. Check system clock is accurate
2. Run step-agent-plugin doctor --renew to force renewal
3. If agent was offline for extended period, certificates may have expired
4. Check agent logs for renewal errors
5. Verify connectivity to your team's CA

Symptoms:

• Runtime requirements check fails
• "Sign with endpoint keys" check fails
• Agent can't create or access keys

Solutions:

1. Windows:
   • Run agent with administrator privileges
   • Verify TPM is enabled in Device Manager
   • Check TPM status: Get-Tpm in PowerShell
2. macOS:
   • Ensure app has keychain access permission
   • Check System Settings > Privacy & Security > Keychain
3. Linux:
   • Check TPM permissions: ls -l /dev/tpmrm0
   • Add user to tss group: sudo usermod -a -G tss $USER
   • Verify tpm2-tss is installed

Symptoms:

• Applications can't access certificates via PKCS#11
• Chrome/Firefox don't see Smallstep certificates
• NetworkManager can't use agent certificates

Solutions:

1. Verify PKCS#11 socket exists and is accessible
2. Set environment variable correctly:

   export P11_KIT_SERVER_ADDRESS=unix:path=$XDG_RUNTIME_DIR/step-agent/step-agent-pkcs11.sock


3. Install p11-kit if not present
4. Test with pkcs11-tool --list-slots
5. See PKCS#11 configuration guide

If you've tried the troubleshooting steps above and still have issues:

1. Run doctor command and save the output
2. Collect agent logs:
   • Linux: sudo journalctl -u step-agent -n 200
   • macOS/Windows: Export logs from the desktop app
3. Note your configuration:
   • Operating system and version
   • Smallstep Agent version (step-agent-plugin version)
   • Any error messages or failure descriptions
4. Contact Smallstep support with the information above

For security issues or private questions, email support@smallstep.com.
